16-Speed Transmission
FAST 16JS200TA
FAST 16JS200TA 16-speed manual truck gearbox: 2,000 N·m rated input torque, ratios 14.03–0.83, 16.5 L oil, 350 kg. Quoted within 24 hours, shipped worldwide.
Features
- Twin-countershaft main and auxiliary sections: 16 speeds in a 2×4×2 layout.
- Optimized short-stroke synchronizers improve shifting, and helical gears in the auxiliary section raise load capacity.
- Revised housing with a port reserved for forced cooling.
- Wide ratio spread with small steps between gears, for varied operating conditions and good fuel economy.
- Several control layouts: single or double lever, remote or direct shift.
Matching Engines
Engines up to 2,000 N·m output torque, such as P11C, WP10 and WP12.
Main Parameters
| Model | 16JS200TA |
|---|---|
| Rated input torque | 2,000 N·m |
| Shift type | Manual |
| Oil capacity | 16.5 L |
| Net weight | 350 kg |
Gear ratios
- Gear 1
- 14.03
- Gear 2
- 11.64
- Gear 3
- 9.60
- Gear 4
- 7.97
- Gear 5
- 6.62
- Gear 6
- 5.49
- Gear 7
- 4.55
- Gear 8
- 3.78
- Gear 9
- 3.08
- Gear 10
- 2.56
- Gear 11
- 2.11
- Gear 12
- 1.75
- Gear 13
- 1.45
- Gear 14
- 1.21
- Gear 15
- 1.00
- Gear 16
- 0.83
- R1
- 13.42
- R2
- 11.13
Rebuilding instead of replacing?
Overhaul kits and internals for the 16JS200TA can be quoted in the same inquiry.
