Weichai Diesel Engine
Weichai WP7H245E62
Weichai WP7H245E62 diesel engine: 180 kW @ 2100 rpm, 1000 Nm @ 1100-1700 rpm, 6.8 L, Euro VI. For truck-mounted cranes and sanitation trucks. Shipped worldwide.
Introduction
Developed from the WP6H with displacement raised from 6.2 L to 6.8 L, built to the engine family's common design with separately arranged intake and exhaust. Power range: 162-235 kW. Emission standard: Euro VI. Applications: 4×2 and 6×2 cargo trucks.
Features
Low fuel consumption
- Separately arranged intake and exhaust improve charging efficiency, combustion and fuel economy.
Lightweight design
- Modular design with an integrated cooling module.
- New materials, including a cast-aluminum flywheel housing.
Low noise and vibration
- Scissor gear train: 77 dB(A) at idle and 91 dB(A) at the peak-torque point.
Powerful
- Torque raised to as much as 1,300 N·m, a specific torque of 191.2 N·m/L.
Clean layout
- Common family design with fewer parts, a simple overall arrangement and neatly routed oil lines and wiring.
Main Parameters
| Model | WP7H245E62 |
|---|---|
| Power / speed (kW / rpm) | 180/2100 |
| Max torque / speed (Nm / rpm) | 1000/1100-1700 |
| Displacement (L) | 6.8 |
| Emission standard | Euro VI |
| Fuel system | CR+DOC+DPF+Hi-SCR |
| Air intake | Turbocharged and intercooled |
| Applications | truck-mounted cranes, sanitation truck |
