WP3NQ150E50
Introduction
Weichai next-generation high-end engine platform product, power range 103-125kW, Euro V/VI emissions. Applied in N2, N3 type light-duty truck.
Features
High reliability
Using wet cylinder liners, portal drum, solid cast iron cylinder head, pistons, connecting rods, The crankshaft, bearing and other moving parts are newly designed, and the B10 has a life span of 800 thousand kilometers
The high-quality supplier of Weichai heavy Card system was adopted and developed in accordance with the high reliability requirements of the heavy Card industry
The block and cylinder head Weichai are self-casting and processing, with high consistency
Excellent NVH performances
Rear gear housing, closed flywheel housing, and plastic cylinder head cover to reduce noise
Standard body reinforcement plate and optional secondary balance mechanism provide lower overall vibration
Ultra-low fuel consumption
Minimum fuel consumption rate 198g/kW•h
powerful
Power 103kW~125kW, maximum torque 520N•m(1400~2100) r/min
High torque, high power and power
Good adaptability
Modular design with compact peripheral accessory placement, a wide range of options and a wide range of applications
N platform product filters, generators, starter and other parts are common and easy to maintain
Main Parameters
| MODEL | WP3NQ150E50 |
|---|---|
| STANDYPOWER/SPEED(KW/rpm) | 110/3000 |
| MAX TROQUE /SPEED(Nm/rpm) | 430/1400-2400 |
| DISPLACEMENT （L） | 2.97 |
| EMISSION STANDARDS | Euro V |
| FUEL INJECTION PUMP TYPE | common rail + SCR |
| INTAKE WAY | Turbocharged and intercooled |
| Adaptable Vehicle | GVW:10-14t cargo truck |
